Description
HDMI 2.0 Switch 7×1 – 7 Input 1 Output 4K 60Hz HDR
The HDMI 2.0 Switch 7×1 allows up to seven compatible HDMI source devices to connect to a single HDMI-equipped TV, monitor or projector. It is designed for AV installations where several HDMI sources need to remain connected while only one source is displayed at a time.
Instead of repeatedly disconnecting and reconnecting HDMI cables, connect your source devices to the seven HDMI inputs and select the required source using the switch controls or supplied remote control.
7 HDMI Inputs to 1 HDMI Output
The switch uses a 7×1 configuration, providing seven HDMI inputs and one HDMI output. This makes it suitable for installations using several HDMI source devices with a single destination display.
This product is an HDMI switch, not an HDMI splitter. It selects one of several HDMI sources for one display rather than duplicating one HDMI source across multiple displays.
HDMI 2.0 with 4K 60Hz Support
The supplied packaging identifies the unit as an HDMI 2.0 Switcher 7×1 and states support for resolutions up to 4K at 60Hz.
This makes the switch suitable for compatible Ultra HD source and display equipment where 4K60 operation is required.
For 4K 60Hz operation, the complete HDMI chain—including the source device, HDMI cables, switch and destination display—must support the required video format.
HDR Support
The packaging states HDR support, allowing the switch to be used in compatible HDR-capable HDMI installations.
HDR performance depends on the connected source, content, HDMI cables and destination display all supporting the required HDR format.
HDCP 2.2 Support
The product packaging specifically states support for HDCP 2.2. This is useful when connecting compatible HDMI source and display equipment that uses HDCP-protected digital content.
36Gbps Data Rate
The supplied product information states support for a 36Gbps data rate. This specification is taken directly from the retail packaging for this model.
24/30/36-Bit Deep Color
The packaging states support for 24-bit, 30-bit and 36-bit deep color, subject to compatibility with the connected HDMI source, content and destination display.
3D Video Support
The HDMI switch also states support for 3D. For 3D operation, the source device, content and destination display must all support the required 3D format.
Remote Control
A remote control is shown as part of the product’s operating configuration, allowing the required HDMI source to be selected without manually changing cables.
This is especially useful when the switch is installed together with several AV source devices in an entertainment centre, meeting room, classroom or equipment cabinet.
Front-Panel Source Selection and Indicators
The HDMI switch features front-panel controls and indicators for convenient source selection and operating-status monitoring.
The product design identifies HDMI inputs from IN1 through IN7, together with output and power indication.
Compatible HDMI Source Applications
The application diagram on the supplied packaging shows the switch being used with several types of HDMI source equipment, including:
- Computers and PCs
- Compatible game consoles
- Set-top boxes
- Blu-ray players
- DVD players
- Other compatible HDMI source devices
The selected source can then be sent to a compatible HDMI TV, monitor or projector.
Suitable Applications
- Home entertainment systems
- Gaming installations
- Conference and meeting rooms
- Classroom and training-room AV systems
- Office presentation systems
- Home theatre installations
- Media rooms
- Showrooms
- AV equipment racks
- Other multi-source, single-display HDMI installations
Product Specifications
| Product Type | HDMI Switch / HDMI Selector |
|---|---|
| Configuration | 7×1 |
| HDMI Inputs | 7 |
| HDMI Outputs | 1 |
| HDMI Standard | HDMI 2.0 |
| Maximum Resolution Stated | 4K 60Hz |
| HDR | Supported |
| HDCP | HDCP 2.2 |
| Data Rate | Up to 36Gbps stated on packaging |
| Deep Color | 24-bit / 30-bit / 36-bit |
| 3D Support | Yes |
| Remote Control | Yes |
| Input Indicators | IN1–IN7 |
| Power Requirement | DC 5V/1A |
| Primary Function | Selects one of up to seven HDMI sources for one compatible HDMI display |
HDMI Cable Length Guidance
The supplied packaging provides specific cable-length guidance for HDMI 2.0 operation. It states an input cable length of up to approximately 3 metres and an output cable length of up to approximately 5 metres for 4K60Hz operation.
Actual performance can depend on HDMI cable quality, source equipment, resolution and connected display. High-quality compatible HDMI cables are recommended, particularly for 4K60 installations.
HDMI Switch vs HDMI Splitter
This HDMI 2.0 Switch 7×1 connects up to seven HDMI sources to one display and allows one source to be selected at a time.
An HDMI splitter performs a different function: it takes one HDMI source and distributes the same signal to multiple displays. Choose this 7×1 switch when you have several source devices but only one destination display.
Before Ordering
Confirm that your source devices and destination TV, monitor or projector support the video resolution and features required for your installation.
For 4K60, HDR and HDCP 2.2 operation, all relevant equipment and HDMI cables in the signal path must be compatible with those features.
Buy an HDMI 2.0 Switch 7×1 in Kenya
Order the HDMI 2.0 Switch 7×1 – 7 Input 1 Output 4K 60Hz HDR from Marcnet Gadgets in Kenya for home entertainment, gaming, conference rooms, classrooms, offices and professional multi-source HDMI installations.
Browse HDMI Splitters & Switchers for related HDMI connectivity products.
Explore more 4K HDMI Switchers at Marcnet Gadgets.
For a closely related option, see 4K HDMI Switch 5×1 – 5 Input 1 Output with Remote.
